General Electric J-100 (1933)
General Electric J-100
Photos donated by Michael Feldt.
Visit Michael's web site at http://www.indianaradios.com/.

To see all the photos Michael has contributed to the Archives, click here.
The J-100 was General Electric's top of the line table model radio for 1933. This radio was actually manufactured by RCA-Victor which manufactured its own version as the R-74. The J-100 was essentially a 10 tube console radio chassis housed in an elaborate cathedral cabinet and the whole set weighed in at a hefty 44 pounds. I purchased this set in May of 2000 at the IHRS Spring swap meet which was held in Indianapolis, Indiana.

Tube Line Up:
58...R.F. Amplifier
58...1st. Detector
56...Heterodyne Oscillator
58...I.F. Amplifier
56...A.V.C.
56...2nd. Detector
56...1st Audio
46 x 2...Push - Pull Audio Output
82...Rectifier
