|I purchased this receiver in August 2005 from fellow collector Jay Volke while attending the ARCI's "Radiofest" in Bolingbrook, Illinois. This set is essentially a NOS piece since it had remained in its original packing box since 1941 and there is no evidence to indicate that it had ever been used.|
Tube Line Up:
6SK7G...1st. I.F. Amplifier
6SK7G...2nd. I.F. Amplifier
7A6G...Detector / AVC
6J5G...Audio Input Indicator Level Control
7C7G...1st. Audio Driver
6J5G...2nd. Audio Driver
6F6G x 4...Push - Pull / Parallel Audio Output
5Y3 x 2...Rectifiers
LW Band (E)...125 kHz - 350 kHz
BC Band (A)...550 kHz - 1600 kHz
SW Band (B)...1.6 MHz - 4.3 MHz
SW Band (C)...4.6 MHz - 12.5 MHz
SW Band (D)...12 MHz - 30 MHz
