|Photos donated by Michael Feldt.|
Visit Michael's web site at http://www.indianaradios.com/.
To see all the photos Michael has contributed to the Archives, click here.
|I aquired this set at the 2004 Radiofest which was held at Elgin, Illinois.|
Tube Line Up:
6A8M...1st. Detector / Oscillator
6Q7M...2nd. Detector / AVC / Audio Driver
BC Band ...550 kHz - 1800 kHz
P Band ...1.7 MHz - 6 MHz
SW Band ...6 MHz - 18 MHz
Rear photo courtesy of Tim Moen.
